Bottle TrapsModel ANA-021
Oceandell Adjustable Brass Bottle Trap Product code ANA-021
Adjustable bottle trap designed for under-sink drainage installations. Manufactured from durable SUS304 stainless steel, it combines a compact round trap body with an adjustable vertical inlet and an extended horizontal outlet pipe. The internal water seal helps prevent unpleasant odours from returning through the drainage system, while the removable lower section supports convenient maintenance and cleaning. The warm bronze brushed finish creates a refined appearance suitable for exposed installations beneath contemporary washbasins.
- Product type
- Accessories
- Model
- ANA-021
- Dimensions
- Width: 50 mm · Height: 120–220 mm · Depth: 300 mm
- Product family
- Bottle Traps
Local availability, compatible components and final installation requirements are confirmed by Aquatop before ordering.
Model ANA-021
Product references
Use the complete product code when requesting this Oceandell model. Each configuration or finish may have its own reference and GTIN.
| Configuration | Product code | GTIN | Product view |
|---|---|---|---|
| Pickaxe Gold - Brushed (PGC) | ANA-021-PGC | On request | View reference |
| Pickaxe Gold - Brushed (PG) | ANA-021-PG | On request | View reference |
| Pickaxe Gold Mirror (PGM) | ANA-021-PGM | On request | View reference |
| Vibrant Bronze - Brushed (BV) | ANA-021-BV | On request | View reference |
| Bright Silver – Polished (BS) | ANA-021-BS | On request | View reference |
| Snow White - Matte (SW) | ANA-021-SW | On request | View reference |
| Light Luxury Gold - Brushed (LG) | ANA-021-LG | On request | View reference |
| Matte Black | ANA-021 | On request | Selected |
Planning data
Details and installation
- Dimensions
- Width: 50 mm · Height: 120–220 mm · Depth: 300 mm
- Product family
- Bottle Traps
- Installation
- Under sink
Official Oceandell resources
View official Oceandell product pageInformation is referenced from official Oceandell material. Product availability and specifications may vary by market; use the latest approved local technical document for final coordination.
Features and design
- Depth: 300 mm
- Shape: Round
- Width: 50 mm
- Height: 120–220 mm
- Surface: Warm Bronze Brushed
- Material: SUS304 stainless steel
- Installation: Under sink
- Product Type: Bottle trap / Sink waste
- Body Diameter: 50 mm
- Coupling Diameter: 43 mm
- Outlet Pipe Diameter: 32 mm
- Wall Flange Diameter: 70 mm
- Wall Flange Thickness: 10 mm
- Adjustable Inlet Range: 10–100 mm
Key features
DepthShapeWidthHeightSurfaceMaterialInstallationProduct TypeBody DiameterCoupling DiameterOutlet Pipe DiameterWall Flange Diameter
Confirm water connections, waste position, mounting support, electrical provision and service access for the exact product reference before site installation.
