Pwt™Model MCR-282
Sloan MCR-282 Product code 0375295
The MCR-282 USB Port-Connector is used to connect Sloan PWT MCR Series Communicating Controllers to the Sloan PWT Management Systems. The USB Port- Connector installs into your Sloan PWT Management Systems USB ports and connects to the MCR Series Controllers using TP/FT-10 Free Topology Twisted Pair (ANSI/CEA-709.3). Removable spring clamp and screw terminal connectors included LED Indicators: Service (amber), Transmit (green), Receive (green). Sloan offers desktop and laptop PWT Management System options that come with different features and capabilities depending on your facilities needs. Regardless of which Management System you choose they call come with alerts for usage violations, alert logs and reports, and remote fixture activations and controls.
- Product type
- Accessories
- Model
- MCR-282
- Dimensions
- See official Sloan specification sheet
- Installation
- Confirm installation requirements with Aquatop
Selected reference
0375295
Local availability, compatible components and final installation requirements are confirmed by Aquatop before ordering.
Planning data
Details and installation
- Dimensions
- See official Sloan specification sheet
- Installation
- Confirm installation requirements with Aquatop
- Installation
- Confirm installation requirements with Aquatop
Official Sloan resources
Programmed Water Technologies (PWT) BrochureBrochure0375295 product specificationSpecification sheet
View official Sloan product page Information is referenced from official Sloan material. Product availability and specifications may vary by market; use the latest approved local technical document for final coordination.
Features and design
- Connects MCR-4001/MCR-4011 series Communicating Controllers
- U10 USB Network Interface connects to a TP/FT-10 Free Topology Twisted Pair (ANSI/CEA-709.3)
- Removable spring clamp and screw terminal connectors included LED Indicators: Service (amber), Transmit (green), Receive (green)
Key features
NOM Certified
Confirm water connections, waste position, mounting support, electrical provision and service access for the exact product reference before site installation.
