SERIES SPECIFICModel 34458980

Showerpipe with shower thermostat without hand shower FlowReduce

Showers · Shower systems · Shower Pipes

Select finish

Brushed Light Gold (PVD)

Availability, compatibility, and final specification are confirmed by Aquatop before ordering.

Model 34458980

Use the complete article number when requesting this Dornbracht model. Each finish has its own article number and GTIN.

Finish	Article number	GTIN	Product view
Chrome	34458980-00	4099477116914	View finish
Brushed Bronze (PVD)	34458980-42	4099477289687	View finish
Brushed Champagne (22kt Gold)	34458980-46	4099477116976	View finish
Brushed Chrome	34458980-93	4099477116990	View finish
Brushed Dark Brass (PVD)	34458980-39	4099477401119	View finish
Brushed Dark Platinum	34458980-99	4099477117003	View finish
Brushed Durabrass (23kt Gold)	34458980-28	4099477116952	View finish
Brushed Gold (PVD)	34458980-37	4099477437583	View finish
Brushed Light Gold (PVD)	34458980-27	4099477209708	Selected
Brushed Platinum	34458980-06	4099477116921	View finish
Champagne (22kt Gold)	34458980-47	4099477116983	View finish
Dark Chrome	34458980-19	4099477116945	View finish
Matte Black	34458980-33	4099477116969	View finish
Platinum	34458980-08	4099477116938	View finish

# Rain shower:
rain shower 300 x 240mm
Rain shower: PURE RAIN, max. flow rate 12 l/min (at 3 bar)
Function from: 12 l/min
quick clearing
rain shower with anti-scale system
# Hand shower:
# Control element:
rotary diverter with volume control and shut-off function
slide-on rosettes Ø 70 mm
metal shower hose 1750mm with integrated anti-twist protection
slide bar
# Technical data:
shower with fixed riser projection 453mm
height of fittings up to rain shower (bottom edge) 985mm
height of fittings up to top edge of elbow 1170mm
Pipe diameter 23.5 mm
gauge 150 mm - 13 mm
1/2" connection
# Notes:
This product can help a building meet the requirements of Green Building Rating Systems, e.g. LEED®, BREEAM®, DGNB
